Rupal Metals, Delhi, India, is a name that can be relied upon for producing and supplying superior Incoloy Flat Bars that have high strength and resistance to oxidation and corrosion at elevated temperatures. Rupal Metals, with years of experience and dedication to quality, supplies Incoloy Flat Bars meeting international standards and are well-suited for different industrial applications. The firm specializes in precision engineering, timely shipments, and customer satisfaction, serving domestic and international markets. For heat exchangers or furnace parts, Rupal Metals guarantees unparalleled durability and performance with each Incoloy Flat Bar delivered.
Incoloy Flat Bars are made up mainly of nickel (42–46%), chromium (19–23%), and iron, with other elements like molybdenum, titanium, and copper adding corrosion resistance and mechanical strength. These bars have a tensile strength of as much as 85 ksi (586 MPa), a yield strength of 35–45 ksi (241–310 MPa), and very good creep resistance at high temperatures. The alloy has good ductility and impact strength after extended exposure to severe heat, and it is thus perfect for hostile environments and thermal processing.
Standards: EN, DIN, JIS, ASTM, BS, ASME, AISI
Size: 5 mm To 500 mm Dia
Length : 100 mm To 3000 mm Long & Above
Specifications : ASTM B425 / SB425
Form : Flat
Finish : Bright, Polish & Black
| Density | g/cm3 | 7.94 | |
|---|---|---|---|
| lb/in.3 | 0.287 | ||
| Melting Range | °F | 2475 – 2525 | |
| °C | 1357 – 1385 | ||
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell, max | |
| Hot worked, as-hot-worked | 550 | 240 | 25 | … | … |
| Cold-worked and hot-worked, annealed | 515 | 205 | 30 | … | … |
Incoloy flat bars are used to manufacture components such as turbine blades, heat exchangers, valves, and fittings that must withstand high temperatures and harsh environmental conditions, ensuring long-term performance and reliability.
Incoloy flat bars are made from high-performance alloys, primarily composed of nickel, chromium, and iron. They may also contain molybdenum, copper, and titanium to enhance corrosion resistance, strength, and durability at high temperatures.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@rupalmetals.com
Incoloy Flat Bars are utilised extensively in a range of industries due to their resistance against severe chemical and high-temperature conditions. They are found in applications like chemical processing, power generation, heat exchangers, marine exhaust systems, and aerospace applications. Their greater resistance to scaling, carburization, and oxidation helps them find application in furnace parts that have high temperatures and industrial heaters. In oil and gas applications, they are reliable in sour gas and chloride-bearing environments. Their weldability and formability also increase their use in structural and fabrication applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Rupal Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Delhi, India
