Ojas Pipes and Tubes, located in Kolkata, India, has earned a solid reputation as a reliable manufacturer and supplier of high-performance Nickel Alloy Bars and Rods. Our products are designed to withstand the tough demands of industries that need exceptional corrosion resistance, heat resistance, and mechanical strength. We use cutting-edge technology and top-quality nickel alloys to craft these bars and rods, ensuring they are durable and perform well even in extreme conditions. We serve a diverse array of industries, including chemical processing, marine, aerospace, and power generation, consistently delivering products that meet both Indian and international quality standards with accuracy and dependability.
Nickel Alloy Bars and Rods mainly consist of Nickel (Ni) along with other elements like Chromium (Cr), Iron (Fe), Molybdenum (Mo), and Copper (Cu), depending on the specific grade (like Inconel, Monel, or Hastelloy). These components provide outstanding oxidation resistance, thermal stability, and mechanical strength. The typical tensile strength ranges from 75,000 to 120,000 psi, maintaining high ductility and toughness even at elevated temperatures. Additionally, these alloys show remarkable resistance to acid attacks, stress corrosion cracking, and pitting, making them perfect for challenging operating conditions.
Nickel Round Bar Specification : ASTM B160, ASME SB160
Dimension Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 14mm-300mm
Thickness : 50 mm to 6000 mm Long
Length : 1 To 6 Meters, Custom Cut Length
Form : Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | UNS | WNR. | JIS | EN |
|---|---|---|---|---|
| Nickel 200 | N02200 | 2.4066 | NW 2200 | Ni 99.2 |
| Nickel 201 | N02201 | 2.4068 | NW 2201 | LC-Ni 99 |
Yes, Nickel Alloy Rods can be customized in size and length to meet specific requirements. Customization options include various diameters and lengths based on customer needs.
Yes, Nickel Alloy Bars are highly corrosion-resistant, especially in harsh environments like acids and seawater. They offer excellent protection against oxidation, pitting, and stress corrosion cracking.
Nickel Alloy Bars are known for their exceptional corrosion resistance, high-temperature strength, and excellent mechanical properties. They also offer good weldability, fatigue resistance, and durability in extreme conditions.
Nickel Alloy Bars and Rods find extensive applications in chemical processing plants, aerospace engines, marine hardware, and power generation facilities, where they often face high temperatures, pressures, and corrosive environments. Their exceptional corrosion resistance makes them perfect for heat exchangers, nuclear reactors, pumps, valves, and fasteners. In the electronics and instrumentation fields, they are utilized in connectors, resistors, and thermocouples. These bars and rods are also vital in producing jet engine components, gas turbines, and marine propulsion systems, ensuring durability, reliability, and performance in critical and harsh environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
