Rupal Metals is a well-established Delhi-based manufacturer and supplier of high-performing metal alloys like MP35N Bar and Rod. With stringent emphasis on quality and precision, Rupal Metals offers material that satisfies the most demanding requirements of numerous industries. Our MP35N rods and bars are produced under the latest technology and strict quality control, guaranteeing optimum strength, corrosion resistance, and durability. Supported by decades of experience, we supply clients in aerospace, medical, marine, and industrial industries with dependable supply solutions that meet their needs. Rupal Metals is your go-to partner for high-quality MP35N alloy products.
MP35N Bar and Rod is a nickel-cobalt alloy with high strength and corrosion resistance that contains about 35% nickel, 35% cobalt, 20% chromium, and 10% molybdenum. It provides good resistance to stress corrosion cracking and hydrogen embrittlement. Mechanically, MP35N has a minimum ultimate tensile strength of 200 ksi (1380 MPa), and can be cold worked and aged to provide additional strength. It maintains high toughness and ductility even under the most harsh environments, and is best suited for demanding applications. Its chemical composition and mechanical strength combine to provide long-term performance in harsh environments.
| Standards : | ASTM F562 / ASME SF562 |
| Thickness : | Range from .008″ to .0125″ |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form : | Round Bar, Wire |
| Grades | HA 190 / HA 1925 / HA 195 / HE 390 / HE 3925 / HE 395 / HE 397 |
|
Cr |
20 nom |
|
Ni |
35 nom |
|
Mo |
10 nom |
|
Co |
35 nom |
| Material | Condtion | Ultimate Tensile Strength ksi | 0.2 % Yield Strength ksi | Elongation % | Reduction of Area % | Hardness HRC |
| MP35N AMS 5844 | Solution Heat Treated and Work Strengthened | 255 | 225 | 12 | 50 | 45 |
| MP35N AMS 5845 | Solution Heat Treated and Work Strengthened and Aged | 260 | 230 | 8 | 35 | 38 min |
| PHYSICAL PROPERTIES | ||||||
|---|---|---|---|---|---|---|
| Density | Electrical conductivity (% IACS) | Thermal conductivity (BTU-in/hr-ft²-°F) | Specific heat capacity | Thermal expansion (1/°F) | Melting Point (°F) | |
| 0..305 | 1.67 | 78 | 0.12 | 0.00000711 | 2510 | |
Yes, MP35N bars can be recycled after use. As a high-performance alloy, it can be melted down and reused to produce new components without significant loss of quality.
MP35N rods are sized based on their diameter and length, typically ranging from 1/16" to 6" diameter and custom lengths, depending on application requirements and manufacturing specifications.
MP35N rods are available in various sizes, typically ranging from 1/8" to 8" in diameter. Common finishes include cold drawn, hot rolled, and annealed for enhanced machinability and surface quality.
MP35N Bar and Rod finds extensive application in environments needing superior strength, corrosion resistance, and reliability. In the aerospace sector, it is utilized in fasteners, springs, and high-stress and corrosion-resistant structural parts. MP35N is utilized by the medical sector in surgical equipment and orthopedic devices because it has biocompatibility. It’s also used in marine and subsea operations, such as pump shafts and valve parts, because of its corrosion resistance in seawater. Oil and gas sectors utilize MP35N for downhole equipment and tools subjected to harsh pressures. Its adaptability makes it a necessity in high-performance engineering applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
