Rupal Metals, located in Delhi, India, stands out as a reliable manufacturer and supplier of top-notch Alloy Steel F5 Bars and Rods, specifically crafted for high-temperature and high-pressure applications. This chromium-molybdenum steel, known as Alloy Steel F5, boasts remarkable strength, thermal stability, and resistance to corrosion. At Rupal Metals, we ensure that our F5 bars and rods are produced with precision and in line with international standards, making them perfect for use in industries like petrochemical, power generation, and refineries. With cutting-edge production methods and a strong commitment to quality and timely delivery, we provide durable, custom-sized alloy bars and rods tailored to meet the toughest engineering challenges.
Alloy Steel F5 is a low-alloy steel containing 5% Chromium and 0.5% Molybdenum, celebrated for its strength at high temperatures and resistance to oxidation. Its typical makeup features Chromium (4.0–6.0%), Molybdenum (0.45–0.65%), along with trace amounts of Carbon, Manganese, Silicon, and Phosphorus. This material delivers impressive tensile strength ranging from 415–585 MPa, yield strength between 205–310 MPa, and moderate elongation. F5 steel is heat-treatable, ensuring excellent performance in high-temperature settings. It is often normalized and tempered to enhance its mechanical properties and extend its service life in critical pressure-bound applications.
Size : 100 to 6000mm Length and 5 to 500mm Dia.
Standard Specification : ASME SA182/ ASTM A182
Diameter : 10 To 200 mm
Specification : EN, DIN, JIS, ASTM, BS, ASME, AISI
Length : 1000 To 6000 mm Long
Form : Square, Round, Rectangle, Hex (A/F), Ingot, Billet, Forging Etc
Thickness : 0.5 to 500mm Diameter
Finish : NO.4 Finish, Matt Finish, BA Finish, Black, Bright Polished, Rough Turned
| Grade | Mn | Others | C | Si | Cr | Mo | P |
| ASTM A182 F5 | 0.30-0.60 | – | 0.15 Max | 0.50 Max | 4.0-6.0 | 0.44-0.65 | 0.035 Max |
| Grade | Tensile Strength (ksi) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (ksi) min | Hardness |
| ASTM A182 F5 | 415 | 30 | 205 | – |
| STANDARD | UNS | WERKSTOFF NR. |
| ASTM A182 F5 | K41545 | 1.7362 |
|
SHAPE |
POUNDS PER FOOT |
|---|---|
|
Flat |
Thickness (in.) x Width (in.) x 3.4 |
|
Hexagon |
D2 x 2.945 |
|
Round |
D2 x 2.67 |
|
Square |
D2 x 3.4 |
Alloy Steel F5 Bars and Rods are widely used in aerospace, power generation, and petrochemical industries for high-temperature applications like turbine blades and heat exchangers.
These bars offer exceptional strength, high-temperature stability, and resistance to oxidation, making them ideal for demanding environments.
Alloy Steel F5 Bars and Rods find their primary use in high-pressure and elevated temperature applications. They are commonly utilized in industries such as petrochemical, refinery, oil & gas, and power generation. These bars are perfect for crafting components like pressure vessels, heat exchangers, boilers, steam piping, and fittings. Thanks to F5’s resistance to oxidation and creep, it is the go-to material for parts that need to perform reliably under thermal stress.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Rupal Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Delhi, India
