Rupal Metals is a well-known Delhi-based manufacturer and supplier of a vast array of high-quality stainless steel products, such as Stainless Steel 317 Square Bars/Rods. With their dedication to quality and accuracy, Rupal Metals serves various industries through products of international standards. Their Stainless Steel 317 Square Bars/Rods are prepared by adopting the latest methods of production and subject to stringency tests for quality to ensure durability, corrosion resistance, and mechanical strength. With a strong distribution network and customer–oriented focus, Rupal Metals has established a high reputation in Indian as well as international steel markets.
Stainless Steel 317 Square Bars/Rods consist of a core of iron with high percentages of chromium (18–20%), nickel (11–15%), and molybdenum (3–4%) to improve corrosion resistance. They also have trace amounts of carbon, manganese, silicon, sulfur, and phosphorus. Stainless Steel 317 Square Bars/Rods possess very good mechanical properties with a tensile strength of approximately 75,000 psi and yield strength of 30,000 psi. They possess good elongation and hardness. Molybdenum content renders them particularly resistant to crevice corrosion and pitting in chloride environments to provide higher performance under severe industrial conditions.
Stainless Steel 317 Square Bars Specification :
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317 | 0.08 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi ” 75000, MPa ” 515 | Psi ” 30000, MPa ” 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 317 | 1.4449 | S31700 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 317 square bars can be welded using conventional welding methods. However, pre-heating and post-weld heat treatment may be required to avoid cracking.
Yes, Stainless Steel 317 square rods can be heat-treated, typically through solution annealing. However, they are not hardenable by heat treatment like some other stainless steels.
Stainless Steel 317 Square Bars offer excellent corrosion resistance, particularly against chlorides and acids, along with high strength and durability. They are widely used in chemical, petrochemical, and food processing industries.
Stainless Steel 317 Square Bars/Rods are extensively employed in petrochemical, pulp and paper, chemical processing, and marine applications owing to their high corrosion resistance in hostile environments. Due to their hardness and strength, they are well suited for use in heat exchangers, condensers, and evaporators. They are also employed in food and beverage processing machinery, drugs manufacturing, and pollution control systems. Square bars/rods are also utilized in structural members where higher corrosion resistance and mechanical strength are important to ensure long service life and low maintenance expenses in various harsh environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
