Rupal Metals is a prominent producer and supplier of high-quality Stainless Steel 347H Round Bars and Rods in Delhi, India. Precision engineering and unbeatable durability make us renowned in the industry, and our products are crafted to satisfy the stringent requirements of commercial and industrial markets. With experience in stainless steel processing spanning years, we guarantee every bar and rod conform to global standards. Our dedication to quality, timely delivery, and customer satisfaction has resulted in a renowned name for steel. We serve numerous industries such as petrochemicals, power generation, and construction, striving for excellence with every product.
Stainless Steel 347H Round Bars and Rods are stabilized austenitic stainless steels comprising chromium (17–19%), nickel (9–13%), and columbium (niobium) for increased corrosion resistance and heat resistance strength. The “H” designation refers to high carbon content for improved creep resistance. The rods have a tensile strength of 515 MPa (minimum), yield strength of 205 MPa (minimum), and elongation of 40% (minimum). They are stable in high-pressure conditions and at high temperatures up to 1000°C. Their enhanced mechanical strength and heat stability make them ideal for challenging industrial conditions.
Stainless Steel Round Bar Specification : ASTM A276 / A479, ASME SA276 / A479
Dimension Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 14mm-300mm
Thickness : 50 mm to 6000 mm Long
Length : 1 To 6 Meters, Custom Cut Length
Form : Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.
| Grade | C | Mn | Si | P | S | Cr | Ni | Ti |
| 347H | 0.04 – 0.10 | 2.00 max. | 0.75 max. | 0.045 max. | 0.03 max. | 17.0 – 19.0 | 9.0-13.0 | 8 x C min. |
| (1.00 max.) |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 347H | 1.4961 | S34709 |
When selecting Stainless Steel 347H Round Bars and Rods, consider factors such as high-temperature resistance, corrosion resistance, mechanical strength, fabrication requirements, and cost-effectiveness for your specific industrial application.
Yes, Stainless Steel 347H Round Bars and Rods can be welded. Their niobium content ensures excellent weldability, making them ideal for high-temperature applications when using appropriate filler materials.
Stainless Steel 347H Round Bars and Rods do not have a specific pressure rating. However, they are suitable for high-pressure applications due to their strength, corrosion resistance, and high-temperature stability.
Stainless Steel 347H Rods and Round Bars are extensively applied to high-pressure and high-temperature services because of their higher resistance to corrosion and oxidation. They are predominantly used in heat exchangers, furnace parts, exhaust manifolds, and boiler tubes and are best suited for petrochemical, aerospace, power generation, and chemical processing. These rods are also utilized in cyclically heated equipment or environments where welding is required because their stabilized composition reduces intergranular corrosion. Their weldability, strength, and durability make them an optimum solution for mechanical and structural components that run under severe conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
