Rupal Metals is a well-known Delhi, India-based manufacturer and supplier of high-quality Stainless Steel 410 Round Bars and Rods. Driven by the focus on precision engineering and highest material standards, Rupal Metals serves varied industrial requirements throughout the nation. Their SS 410 round bars and rods are famous due to their excellent mechanical strength, corrosion resistance, and durability. With state-of-the-art manufacturing plants and rigorous quality control measures, Rupal Metals guarantees each product to be up to national and international standards, providing reliable stainless steel solutions to industries including construction, automotive, petrochemical, and engineering.
410 Round Bars and Rods of Stainless Steel are martensitic stainless steels containing a major proportion of 11.5–13.5% chromium, 0.75% nickel, up to 1% manganese, 0.15% carbon, and minute quantities of silicon, sulfur, and phosphorus. These bars provide very good hardness, tensile strength (up to 700 MPa), and average corrosion resistance. The Brinell Hardness may vary from 170 to 223 based on heat treatment. The material also has good ductility and impact resistance, particularly in temper condition. Such mechanical and chemical attributes enable SS 410 bars and rods to be applicable in high-stress and slightly corrosive environments.
Stainless Steel Round Bar Specification : ASTM A276 / A479, ASME SA276 / A479
Dimension Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 14mm-300mm
Thickness : 50 mm to 6000 mm Long
Length : 1 To 6 Meters, Custom Cut Length
Form : Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.
| Element | S | Cr | Si | C | P | Mn | Ni |
| SS 410 | 0.030 | 11.5-13.5 | 1.00 | 0.15 | 0.040 | 1.00 | 0.75 |
| Elongation | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength |
| – | – | MPa – 275 | – | MPa – 480 |
| STANDARD | UNS | BS | EN | JIS | WERKSTOFF NR. | GOST | AFNOR |
| SS 410 | S41000 | 410S21 | 56A | SUS 410 | 1.4006 | – | – |
Type | SIZES (Inches) | ISO Tolerance | SIZES (mm) |
|---|---|---|---|
Peeled and Polished | 1.50″ to 6.00″ | h11-DIN 1013 | 40.00 to 150.00 |
Cold Drawn and Ground | 5/6″ to 2.50″ | h9-h8-h11-h10 | 10.00 to 75.00 |
Cold Drawn and Polish | 1/8″ to 3.00″ | h9-h8-h11-h10 | 3.00 to 75.00 |
Peeled and Ground | 3/4″ to 2.00″ | h10-h9-h11 | 20.00 to 50.00 |
Cut to size on request (tolerance +2/-0 mm). 410 Stainless Steel Bars Standard lengths of 2000 mm up to 6000 mm.
50.0 | 6.0 |
45.0 | 5.0 |
60.0 | 8.0 |
55.0 | 7.0 |
70.0 | 10.0 |
65.0 | 9.0 |
75.0 | 12.0 |
90.0 | 20.0 |
80.0 | 16.0 |
100.0 | 25.0 |
160.0 | 35.0 |
130.0 | 30.0 |
200.0 | 40.0 |
Cut to size on request (tolerance +2/-0 mm). Standard lengths of 904L Stainless Steel Bars 2000 mm up to 6000 mm available
5.0 | 45.0 |
6.0 | 50.0 |
7.0 | 55.0 |
8.0 | 60.0 |
9.0 | 65.0 |
10.0 | 70.0 |
12.0 | 75.0 |
16.0 | 80.0 |
20.0 | 90.0 |
25.0 | 100.0 |
30.0 | 130.0 |
35.0 | 160.0 |
40.0 | 904L.0 |
Stainless Steel 410 Round Bars/Rod generally does not require additional corrosion protection coatings, as it offers moderate corrosion resistance due to its chromium content. However, in highly corrosive environments, coatings may enhance durability.
When selecting Stainless Steel 410 Round Bars/Rod, consider factors like strength requirements, corrosion resistance, heat treatment needs, and the specific application environment to ensure optimal performance and durability.
Stainless Steel 410 Round Bars/Rod is not ideal for hygienic and sanitary applications due to its moderate corrosion resistance. For such uses, higher grades like 304 or 316 are recommended for better resistance.
410 Stainless Steel Round Bars and Rods are used extensively in high-strength applications, wear resistance, and moderate corrosion protection. Typical uses are to make valves, pumps, shafts, and fasteners for the oil and gas, petrochemical, and power generation industries. Their machinability also suits them for auto parts such as axles and gears. They are also used in industrial equipment, kitchen appliances, and building structures because of their strength and durability. The fact that the material can maintain strength at elevated temperatures renders it as a favored option in heat treatment and engineering applications that require endurance and hardness.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
