Ojas Pipes and Tubes, located in Kolkata, India, stands out as a top manufacturer and supplier of Stainless Steel 904L Round Bars and Rods, celebrated for their exceptional quality, precision, and durability. With a focus on high-performance alloys, Ojas provides 904L stainless steel products that are specifically designed to endure highly corrosive environments, including those found in marine, chemical, and pharmaceutical sectors. Committed to upholding international standards and ensuring customer satisfaction, the company guarantees timely deliveries and tailored dimensions. Engineers and fabricators trust their 904L round bars and rods for critical applications that demand outstanding resistance to acids and extreme conditions.
Stainless Steel 904L Round Bars and Rods boast high levels of chromium (19–23%), nickel (23–28%), molybdenum (4–5%), and a touch of copper (1–2%) to provide remarkable corrosion resistance. This low-carbon austenitic alloy excels in resisting pitting, stress corrosion cracking, and crevice corrosion. With a tensile strength of around 490 MPa, yield strength of about 220 MPa, and an elongation of roughly 35%, it delivers impressive mechanical performance even in harsh environments. 904L is non-magnetic, weldable, and can be easily machined with the right tools, making it ideal for specialized industrial applications.
| Standards | ASTM / ASME |
| Designation | B 649, SB 649 |
| Grade | 904L Round Bars and Rods 904L Round Bars and Rods: ASTM B 649, ASME SB 649 |
EN/DIN | 1.4539 X1NiCrMoCu25-20-5 |
|---|---|
AFNOR | Z2CNDU25.20 |
UNS | N08904 |
AISI | 904L / F904L |
BS | 904S13 |
SS | 2562 |
OTHER | ASTM A182 ASTM A262 ASTM A479 ASTM B649 / ASME SB649 DIN 17440 EN10088-3 EN10272 NACE MR01-75 / ISO 15156 SEW 400-VdTÜV421 |
BRANDS | URANUS B6™ VLX904™ AL-904L™ CRONIFER 1925™ 2RK65™ |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|---|
| SS 904L | 0.020 max | 2 max | 1 max | 0.040 max | 0.030 max | 19.0-23.0 | 4.0-5.0 max | 23.00 – 28.00 | 1.0-2.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35% |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
Cut to size on request (tolerance +2/-0 mm). Standard lengths of 904L Stainless Steel Bars 2000 mm up to 6000 mm available
5.0 | 45.0 |
6.0 | 50.0 |
7.0 | 55.0 |
8.0 | 60.0 |
9.0 | 65.0 |
10.0 | 70.0 |
12.0 | 75.0 |
16.0 | 80.0 |
20.0 | 90.0 |
25.0 | 100.0 |
30.0 | 130.0 |
35.0 | 160.0 |
40.0 | 904L.0 |
Yes, Stainless Steel 904L Round Bars/Rod can be easily welded, machined, and fabricated, offering excellent work ability due to its high nickel and chromium content, ensuring durability and resistance to corrosion.
Yes, Stainless Steel 904L Round Bars/Rod can be used at high temperatures, typically up to 1000°F (537°C), maintaining excellent corrosion resistance and strength in elevated thermal environments.
Yes, Stainless Steel 904L Round Bars/Rod can be fully recycled without losing quality. Stainless steel is highly recyclable, making it an eco-friendly material for various applications.
Stainless Steel 904L Round Bars and Rods find extensive use in chemical processing plants, pharmaceutical manufacturing, offshore oil drilling, heat exchangers, and the pulp and paper industry, thanks to their high resistance to strong reducing acids and chloride-rich environments. Their non-magnetic properties and excellent formability also make them perfect for high-purity water systems, gas scrubbers, and seawater equipment. The alloy’s superior corrosion resistance ensures a longer service life in tough industrial conditions, minimizing maintenance downtime. Fabricators and engineers favor 904L for building pressure vessels, piping systems, and welded assemblies.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
